All in One Stacked Lifepo4 Battery Solar Energy Storage Power System Home 48v 51.2v 10KW 15kWh 16kwh 20kWh 25kWh
Product Description:
| Battery Energy Storage |
| Battery Chemistry |
LiFePO4 |
| Default Volage(V) |
25.6V |
| Cell Capacity(Ah) |
314Ah |
| Capacity |
8.038KWh |
| Max.Charging Voltagy(V) |
28.4V |
| Discharge Cut-off(V) |
21.6V |
| Standard Charging Current(A) |
100A |
| Standard Discharging Current(A) |
100A |
| Max.Operation Current(A) |
200A |
|
Dimensions(W*D*H)
Package Dimension(W*D*H)
|
540*240*501.2mm
600*310*570mm
|
|
Net Weight
Gross Weight
|
66KG
83KG
|
|
General Parameters
|
| Scalability |
Max.16 systems in paeallel
|
| Storage Conditions |
-20℃~60℃(0℃~45℃ Recommended) Up to 90%RH,non-condensing Initial SoC:30%
|
| Operating Temperature |
Chare:0℃~40℃
Discharge:-20℃~40℃
|
| Cooling |
Natural Cooling |
| Cell Lifespan |
11000 Cycles@(25℃,100%DOD,0.5P,@70%SOH) |
| Cycle Life |
＞8000 Cycles@20-25℃@100A@90%DOD |
| Built-in Screen |
Y,LCD Touch Screen |
| Communication |
CAN,RS485,RS232,Wifi/Bluetooth(optional) |
| System Characteristic |
| Transportation Certification |
UN38.3,MSDS,CE |
| Installation Method |
Floor Mounting |
| IP Rating |
IP30 |
Applications:
The Floor-Standing Lithium Battery is an advanced energy storage solution tailored for residential and commercial scenarios. Boasting a nominal energy capacity of 16KWh, this battery system delivers dependable power backup for homes and businesses alike, ensuring an uninterrupted electricity supply during power outages or peak demand hours.
A standout attribute of this battery is its integrated natural cooling system, which effectively maintains optimal operating temperatures and extends the service life of battery cells. This innovative cooling technology guarantees efficient and safe performance, making it a perfect fit for high-demand applications.
Engineered to endure a broad spectrum of storage conditions, the Floor-Standing Lithium Battery can operate stably within a temperature range of -10°C to 45°C. Such versatility allows it to be installed in various environments, positioning it as a flexible and reliable energy storage option for diverse settings.
With an IP30 protection rating, this battery provides effective defense against dust and water intrusion, ensuring consistent operation even in harsh outdoor or industrial environments. Its robust construction makes it an ideal selection for off-grid solar setups, backup power systems, and other applications that demand durable and weather-resistant energy storage solutions.
Featuring a floor-mounted installation design, the Floor-Standing Lithium Battery is easy to set up, streamlining the installation process and ensuring stable operation. This user-friendly installation method saves both time and effort, making it a great option for professional installers and DIY enthusiasts who want to seamlessly integrate energy storage into their projects.
Whether you need a reliable backup power source for your home, a sustainable energy storage solution for your business, or a flexible battery system for off-grid use, the Floor-Standing Lithium Battery offers a high-performance and cost-effective answer. Equipped with advanced features, a durable build, and easy installation, it stands out as a top choice for those seeking reliable and efficient energy storage solutions.
Invest in the Floor-Standing Lithium Battery now and enjoy the advantages of a floor-standing battery that delivers exceptional performance, durability, and versatility. Whether you require a Floor Mounted Solar Battery, a floor-standing LiFePO4 battery, or a reliable energy storage solution for your specific needs, this battery system offers the quality and reliability you can count on.
Produced in Shenzhen, the Junext floor-standing lithium battery holds ISO, UN38.3, CE and MSDS certifications, which guarantee compliance with strict safety and quality benchmarks. Its low minimum order quantity enables customers to conveniently procure the product to meet their unique requirements.
The Junext Floor-Standing Lithium Battery is applicable to a broad spectrum of scenarios, including but not limited to:
- Residential energy storage systems
- Commercial energy backup solutions
- Industrial power supply applications
- Solar energy storage systems
This multi-functional battery delivers a nominal energy capacity of 8KWh and boasts a cycle life of 8000 cycles, ensuring sustained performance and long-term durability. Its floor-mounted structure facilitates straightforward installation and seamless integration into diverse setups.
Weighing a mere 66KG net, the Junext floor-standing lithium battery strikes a perfect balance between light weight and high power, making it well-suited for both indoor and outdoor deployment. Equipped with CAN, RS485 and RS232 communication functions, it allows for smooth system integration and real-time battery monitoring.
Customers can take advantage of a dependable supply chain that supports a daily supply capacity of up to 100,000 pieces. Flexible T/T payment terms and a delivery window of 30–60 days further enhance convenience, making this premium Floor Mounted Solar Battery easily accessible to clients.
