230VAC Solar Inverter 6.2KVA 48V Bess Inverter For Personal Computers

Large Image : 230VAC Solar Inverter 6.2KVA 48V Bess Inverter For Personal Computers

Product Details:

Place of Origin:	shenzhen
Brand Name:	JUNEXT
Certification:	ISO、UN38.3、CE、MSDS
Model Number:	JN-E-SUN 6.2KVA/48V

Payment & Shipping Terms:

Minimum Order Quantity:	Low MOQ
Payment Terms:	,T/T
Supply Ability:	200pcs/day

Contact Now Chat Now

230VAC Solar Inverter 6.2KVA 48V Bess Inverter For Personal Computers

Description

Highlight:

230VAC Solar Inverter

Solar Inverter 6.2KVA

48V bess inverter

JN-E-SUN 6.2KVA/48V 230VAC Solar Inverter 6.2KVA 48V Bess Inverter For Personal Computers 0

Product Parameters

New Model	JN-E-SUN 6.2KVA/48V
Max.PV Power	6500W
Rated Power	6200VA
Max.Charge Current	100A
Battery
Battery Voltage	48VDC
Floating Charge Voltage	54VDC
Overcharge Protection	63VDC
Battery Type	Compatible With GEL,AGM,Lithium battery
Grid Input
Voltage	230VAC
Selectable Voltage Range	170-280VAC(For Personal Computers),90-280 VAC (For Home Appliances)
Frequency Range	50 Hz/60 Hz (Auto sensing)
Efficiency(AC Mode)	98%
Ac Output
AC Voltage Regulation(Batt.Mode)	230 VAC 士 5%
Surge Power	12400VA
Efficiency (Peak)	90%-94%
Transfer Time	10 ms(For Personal Computers);20 ms (For Home Appliances)
Waveform	Pure sine mave
Dual Loads Acoutput
Full Load	6200VA
Maximum Main Load	6200VA
Maximum Second Load(Battery Mode)	2100W
Main Load Cut Off Voltage	44VCD
Main Load Retum Voltage	54VCD
Solar Charger&Ac Charger
Solar ChargerType	MPPT
Maximum PV Array Power	6500W
Max. input Current	27A
MPPT Range @ Operating Voltage	90-450VDC
Maximum PV Aray Open Circuit Vollage	500 VDC
Maximum Solar Charge Current	100A
Maximum Ac Charge Curent	100A
Maximum Charge Curent	100A
Physical
Packing Dimension,DWH(mm)	543394204
Net Weight (kg)	10.5
Communication interface	USBIRS232/WIFI/GPRS
Operating Environment
Humidity	5% to 95%6 Relative Humidity(Non-condensing
Operaling Temperature	-10℃ to 50℃
Storage Temperature	-10℃ to 50℃
