832V Liquid Cooled Battery 261KWh Sustainable Bess Energy Storage Solutions

Large Image : 832V Liquid Cooled Battery 261KWh Sustainable Bess Energy Storage Solutions

Product Details:

Place of Origin:	shenzhen
Brand Name:	JUNEXT
Certification:	UN38.3、MSDS、CE、
Model Number:	JNESS0261-0125B

Contact Now Chat Now

832V Liquid Cooled Battery 261KWh Sustainable Bess Energy Storage Solutions

Description

Highlight:

832v liquid cooled battery

liquid cooled battery 261kwh

sustainable bess energy storage solutions

832V DC Liquid Cooled Battery Energy Storage Unit 261KWh Rated Energy for Sustainable Energy Solutions

Product Parameters

Specifications
Model	JNESS0261-0125B
Dimension(LxWxH)	1000x1300x2200mm(Ring hanger is not included)
Weight	2850kg士100kg
Series-parallel Mode	1P260S
Nominal Voltage	DC:832V
Rated Capacity	314Ah
Rated energy	261.25KWh
Operating Voltage	DC:650V~949V
Max Current	200A(DC side)
Overall Efficiency	>88%@25℃士2℃,0.5P
Cycle Life	≥8500 Cycle @25℃士2℃,0.5P,70%SOH
IP Grade	IP54
AC grid-connected
Nominal Voltage	AC:400V(-10%~+15%)
Max Current	AC:180A
Rated power	125kW@25℃士2℃
Maximum Sustained Power	137.5kW@25℃±2℃
Rated grid frequency	50Hz/60Hz
Off-grid output THDU	<3%(linear load)
Nominal Voltage	(3W+N+PE)Three phase four wire
AC Off-Grid
Max Voltage	AC:400V
Max Current	AC:180A
Rated power	125kW@25°C
Rated frequency	50Hz/60Hz
